I offer some boat designs for those who want to build a yacht himself. contact info@amariner.net
Some homebuilding boat yacht and powerboat designs for amauter
4.5m family pocket cruiser Kroha-15 Сenterboard/keel 7.6 metres sailboat (trailer) Gaff cutter BIT 26
Pocket cruiser 15ft plans 25-footer traileable centerboard gaff catter 26

LOA = 4.48м
BOA = 1.96м
LWL = 4.30м
BWL = 1.75м
Displ.= 0.89т
Draft = 0.85м
Ballast = 0.35т
Sail area = 13.4м²
                                    View more >>>

View building process

LOA = 7.6м
BOA = 2,5м
LWL = 6,7м
BWL = 2.0м
Displ.= 1,8/2,3т
Draft = 0,32/1,5м
Ballast = 0.6т
Sail area = 36.0м²                                    View more >>>

View building process

LOA = 8.0м
BOA = 2.9м
LWL = 7.4м
BWL = 2.4м
Displ.= 4.0т
Draft = 0,7/1,9м
Ballast =1.4т
Sail area = 35.0м²                                    View more >>>

View building process

10m sailing yacht S9.9 8,6m centerboard/keel sailing yacht S8,6 11m cruising sailing yacht S11
10 m yacht design senterboard 8m yacht design centerboard 8m design Yacht 11 m design

LOA = 9.90м
BOA = 3.29м
LWL = 9.17м
BWL = 2.73м
Displ.= 545т
Draft = 1.75м
Ballast = 1.5т
Sail area = 54.0м²
                                    View more >>>

View homebuilding

LOA = 8.6м
BOA = 3.02м
LWL = 8,1м
BWL = 2.55м
Displ.= 2.8т
Draft = 0.4/1,6м
Ballast = 1.0т (with fin keel))
Sail area = 41,0м²
                                    View more >>>

LOA = 11.0м
BOA = 3.70м
LWL = 9.9м
BWL = 3.2м
Displ.= 6.3т
Draft = 1.9м
Ballast = 2.2т
Sail area = 61.0м²
                                    View more >>>

View building process

Racer/Cruiser Spiritus 41 sailing yacht PowerBoat CRAB 800 Ocean 44 yacht design
sailing yacht 41 powerboat crab 800 plans ocean yacht 44 feet

LOA = 12.2м
BOA = 2.5м
LWL = 9.0м
BWL = 2.3м
Displ.=4.5т
Draft = 1.9м
Ballast = 2.0
Sail area =60 м²
                               view more >>>

View building process

LOA = 8.0м
BOA = 2.5м
LWL = 7.4м
BWL = 2.2м
Displ.= 2.6т
Draft = 0.57м
Engine = 27hp.
                                           View desigh >>>

View building process

LOA = 13.5м
BOA = 4.2м
LWL = 11.8м
BWL = 4.7м
Displ.= 12т
Draft = 1.95 -2,2м
Ballast = 5,7т
Sail area = 105м²
                              View more >>>

View building process

Catboat-16 Gaff cutter BIT 22 trailerable Race/cruise sailing yacht Ruta 33
Gaff cutter 22 design plans 33 feet sailing yacht design

LOA = 5,0м
BOA = 2.32м
LWL = 4.85м
BWL = 1.90м
Displ.= 0,7/1.0т
Draft = 0.34м/1.0м )
Ballast = 0.14т
Sail area = 18,0м²
                              View more >>>

view building

LOA = 6.7м
BOA = 2.5м
LWL = 6.1м
BWL = 2.0м
Displ.= 1.9т
Draft = 0.8м
Ballast = 780kg
Sail area = 27м²
                              View more >>>

See building

LOA = 10.0м
BOA = 3.4м
LWL = 9.8м
BWL = 2.6м
Displ.= 4.6т
Draft = 1.8м
Ballast = 1.5т
Sail area = 56м²
                              View more >>>

View building process


Design Catboat-23, LongKeel, 7m Gaff cutter BIT 33 Sailing yacht ocean racer S-40
кэтбот 7 метров Gaff cutter 33ft 40ft sailing yacht racer plans

LOA = 6,78м (длина корпуса наибольшая)
BOA = 2.43м (ширина наибольшая)
LWL = 5.9м (длина по ватерлинии)
BWL = 2.05м (ширина по ватерлинии)
Displ.= 1.3 - 1.8т (водоизмещение порожнем/полное)
Draft = 0.85м- (осадка макс. килем кормой)
Ballast = 0.6т (балласт в киле)
Sail area = 28,0м² (площадь гафельного грота)
                              Смотреть проект >>>

building

LOA = 9.9м
BOA = 3.17м
LWL = 8.8м
BWL = 2.77м
Displ.= 5.1/6.0т
Draft = 1.0м
Ballast = 2.5т
Sail area = 56м²
    View more >>>             View building process >>>

Sailing yacht ocean racer S-40
LOA = 12.16м
BOA = 4.4м
LWL = 12,1м
BWL = 3.23м
Displ.= 5,4/6,4т
Draft = 2.95м
Ballast = 2.2т
Sail area = 115м²

View more >>>


Sailing yacht cruiser/racer Tempro-30
sailing yacht 10 metres DIY
LOA = 9.2м
BOA = 3,4м
LWL = 9,2м
BWL = 2.9м
Displ.= 3,2/4,0т
Draft = 1,6м
Ballast = 0.9т
Sail area = 49.0м²
      See yacht design >>>    View yacht homebuilding


PowerBoat P-550 PowerBoat CRAB 900 Keel & rudder design
motorboat 14 ft plans катер 9 метров fin keel design
LOA = 5.48м
BOA = 1.38м
LWL = 5.20м
BWL = 1.20м
Displ.= 0,6т
Draft = 0.48м
Engine =12 hp
Retro design like "Petterssen 550" 1911 year
                              View more >>>


LOA = 9.0м (длина наибольшая)
BOA = 2.5м (ширина наибольшая)
LWL = 8.4м (длина по ватерлинии)
BWL = 2.2м (ширина по ватерлинии)
Displ.= 2,0/3,0т (водоизмещение порожнем/полное)
Draft = 0.67м (осадка при полной загрузке)
Двигатель = 27-70л.с.

View more >>> View building

Fin keel design and producing. Fin kells and keells with bulb for any type of sailing yacht.  View more >>>
Speed PowerBoat Z14 PowerBoat CRAB 620 PowerBoat CRAB 840
speed boat 14ft plans powerboat 6metres катер 8,4 метра

Speed boat Runabout Z-14
LOA = 4,1м
BOA = 1.65м
LWL = 3,5м
BWL = 1.5м
Displ.= 0,14 / 0,45т
Draft = 0.16м
Engine - up to 40 hp .

View more >>>     View Building

LOA = 6,2м
BOA = 2.33м
LWL = 5.87м
BWL = 2.1м
Displ.= 0.85/1,3т
Draft = 0.25м
Engine = 20-115 hp

View more >>>   View building


LOA
= 8,4м
BOA = 2.35м
LWL = 8,1м
BWL = 2.15м
Displ.= 1,3/2,5т
Draft = 0.3м
engine = 20- 150 hp ob

View more >>>


PowerBoat Р-990 Speedster KS-500 Power boat F 115
моторный катер 10 метров мотолодка 5 метров проект
LOA = 10,0м
BOA = 2.47м
LWL = 9,4м
BWL = 2.04м (
Displ.= 2,0/3,0т
Draft = 0.69м
Engine = 20-60 hp


View more >>>
LOA = 5,05м
BOA = 2,0м
LWL = 4,4м
BWL = 1,9м
Displ.= 0.6/0,9 т
Draft = 0.22м
Engine = до 150л.с.
       View more>>>
Смотреть постройку лодки >>>

Смотреть постройку лодки 2 >>>

LOA = 11,56м (длина наибольшая)
BOA = 2.7м (ширина наибольшая)
LWL = 11,2м (длина по ватерлинии)
BWL = 2.5 м (ширина по ватерлинии)
Displ.= 4.0/6,0т (водоизмещение порожнем/полное)
Draft = 0.5м (осадка при полной загрузке)
Engine = 30-250 hp


                              View more>>>


Speed powerboat MRB-6 Workboat MRB-7 Workboat MRB-10
катер служебный 6 метров катер рабочий 7 метров катер скоростной 10 метров

Polyethylene (HDPE) boat
LOA = 6,32м (длина наибольшая)
BOA = 2,48м (ширина наибольшая)
LWL = 5,19м (длина по ватерлинии)
BWL = 2,34м (ширина по ватерлинии)
Displ.= 2,0 т (водоизмещение полное)
Draft = 0.4м (осадка корпусом полное)
Freeboard = 0.5м (надводный борт на миделе)
Engine = 150-250 hp overboard

View more >>>

Polyethylene (HDPE) boat
LOA = 7,2м (длина наибольшая)
BOA = 2,5м (ширина наибольшая)
LWL = 6,4м (длина по ватерлинии)
BWL = 2,3м (ширина по ватерлинии)
Displ.= 1,3/4,0 т (водоизмещение порожнем/полное)
Draft = 0.30 - 0,45м (осадка порожнем/полное)
Freeboard = 0.8м (надводный борт на миделе)
Двигатель = 115-250 hp overboard
Payloaad: 3000 кg.

View more
Polyethylene (HDPE) boat
LOA
= 10,2м (длина наибольшая)
BOA = 3,65м (ширина наибольшая)
LWL = 9,4м (длина по ватерлинии)
BWL = 2,1м (ширина по ватерлинии)
Displ.= 3,0/10,0 т (водоизмещение порожнем/полное)
Draft = 0.3 - 0,6м (осадка корпусом порожнем/полное)
Engine = 2х150-250 hp ouboard

Payloaad
: 6000 кg.

View more

Dinghy 11 Speedster KS-900 SpeedBoat STL-57
проект гребная парусная лодка динги катер глиссирующий 9 метров

LOA = 3,35м (длина наибольшая)
BOA = 1,35м (ширина наибольшая)
LWL = 3,2м (длина по ватерлинии)
BWL = 0,97м (ширина по ватерлинии)
Hull Weight.= 50кг (вес корпуса)
Draft = 0.085м (осадка корпусом)
Sails = 5,5 м2 (парусность)

 View more >>>                 building

LOA = 8,8м (длина наибольшая)
BOA = 2,45м (ширина наибольшая)
LWL = 7,4м (длина по ватерлинии)
BWL = 2,1м (ширина по ватерлинии)
Displ.= 1,1/2,1 т (водоизмещение порожнем/полное)
Draft = 0.35 м (осадка корпусом)
Engine = 2х150-250hp jet

View more >>>>

View Building

LOA = 5,7м
BOA = 2,15м
LWL = 5,22м
BWL = 2,05м
Displ.= 0,75/1,2 т
Draft = 0.4м
Engine = 350л.с.

View more


Fishing Boat SFB-5.4 SpeedBoat STL-7
катер бот рыболовный

Speed Boat 5,4m SFB-5.4
LOA = 5,4м
BOA = 2,42м
LWL = 4,5м
BWL = 1,9м
Displ.= 1,2 т
Draft = 0.3м
Freeboard = 0.65м
Engine = 200hp outboard
Fuel tank: 2х70л.

See more

Катер скоростной морской 9 метров STL-9
LOA = 9,0м
BOA = 2,95м
LWL = 8,31м
BWL = 2,75м
Displ.= 2,6/4,0 т
Draft = 0.5м
Freeboard = 1.0м
Engine = 400hp
Fuel tank: 2х250л. (топливо)

See more

Fishboat Crab 950 Fisher
LOA = 9.7м (длина наибольшая)
BOA = 3.35м (ширина наибольшая)
LWL = 9.4м (длина по ватерлинии)
BWL = 3.0м (ширина по ватерлинии)
Displ.= 4,0/8,0т (водоизмещение порожнем/полное)
Draft = 0.9 м (осадка при полной загрузке)
Engine = 50-70л.с.



See design


Johnboat 3,9 metres SFB-5.4 (HDPE) Tugboat-37 Family
jon boat 4 meters HDPE

Johnboat 3,9 metres SFB-5.4 (HDPE)
LOA = 3,9м
BOA = 1,62м
Displ.= 450 кг
Draft = 0.1-0,16м
Freeboard = 0.52м
Engine = до 25hp outboard

persons: up to 4
Hull weight: 150kg

View project >>>

Powerboat TugBoat-37
LOA = 11.2м
BOA = 3.9м
LWL = 10.1м
BWL = 3.55м
Displ.= 7,0/8,0т
Draft = 1.0 м
Engine = 50-100л.с.

View Project

LOA = 6,85м
BOA = 2.48м
LWL = 6,85м
Displ.= 0,7,0/1,8т
Draft = 0.32м
engine=до 10кВт

see project >>>

                       Speedster KS-400 Classic speedboat 10m Jet ski boat JB-500
проект прогулочный катер 5 метров

Speedboat KS-400
LOA = 3,97м
BOA = 1,70м
Displ.= 530 кг
Draft = 0.17-0,24м
Freeboard = 0.5м
Engine = 25hp overboard

Crew: 4 pers.
Hull weight: 120kg.

Runabot 4metres. Plywood construction

View project>>>

SPEEDBOAT Classic CC-10
LOA = 10,3м (длина наибольшая)
BOA = 2,99м (ширина наибольшая)
Displ.= 2,6/3,7 т (водоизмещение порожнем/полное)
Draft = 0.5м (осадка корпусом порожнем/полное)
Freeboard = 1.0м (надводный борт на миделе)
Двигатель = 400л.с.
Килеватость днища на транце : 18 град.

View design

Jet ski boat JB-500 5meters
LOA
= 5,0м (длина наибольшая)
BOA = 2,70м (ширина наибольшая)
Displ.= 9,6/1,1 т (водоизмещение порожнем/полное)
Draft = 0.25м (осадка корпусом порожнем/полное)
Freeboard = 0,6м (надводный борт на миделе)
Двигатель = 150-300л.с.
Килеватость днища на транце : 16 град.

Пассажиров: 5+1

View design

TugBoat CRAB-700


TugBoat 7 meters
LOA
= 6,9м
BOA = 2,48м
Draft = 0,60м
Displ.= 2,0т
Engine = 13-20 hp
Speed = 14 км/час (скорость хода)
Passengers: up to 6 p.
Носовая каюта, гальюн, камбуз, рулевая рубка. кокпит
Трейлерный катер в стиле буксира

see project >>>
